• HC209 Eccentric Bore Insert Ball Bearing 45mm Bore Standing Side View
  • HC209 Eccentric Bore Insert Ball Bearing 45mm Bore Back View
  • HC209 Eccentric Bore Insert Ball Bearing 45mm Bore Side View

    • HC209 Insert Ball Bearing 45x85x56.3

    Minimum Order: 100 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    HC209
    Minimum Purchase:
    100 units
    Inner Diameter:
    45mm
    Outer Diameter:
    85mm
    Inner Race Width:
    22mm
    Outer Race Width:
    56.3mm
    Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Static Load:
    4,610 lbs
    Dynamic Load:
    7,390 lbs
    Speed Limit:
    3,700 RPM
    Interchange Numbers:
    NA209, HC209, UG209

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    HC200 Bearing Series is Precision Eccentric Bore Insert Ball Bearing With Locking Collar Set Screw, Sealed and Pre-Lubricated with Grease

    HC200 Insert Bearing Series has a combination of a standard lubrication feature that has a drilled hole in the groove on the locking collar and to make things more efficient the drilled oil hole opposite to the collar to make it interchangeable with the different manufactures. This Insert Bearing is self aligning for standard load capacity. This specific bearing has an eccentric cam locking collar for the attachment of the shaft.

    Match#: NA209, HC209, UG209

    Product Videos

    Custom Field

    Inner Diameter 45mm
    Outer Diameter 85mm
    Inner Race Width 22mm
    Outer Race Width 56.3mm
    Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Static Load 4,610 lbs
    Dynamic Load 7,390 lbs
    Speed Limit 3,700 RPM
    Interchange Numbers NA209, HC209, UG209
