• SUCVP201-8 Stainless Steel Ball Bearing in Plastic Pillow Block Unit 1/2" Front View
  • SUCVP201-8 Stainless Steel Ball Bearing in Plastic Pillow Block Unit 1/2" Back View

    • 1/2" bore SUCVP201-8 Stainless Steel Ball Bearing Plastic Pillow Block Unit YAS-1/2-PT

    Minimum Order: 100 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    SUCVP201-8
    Minimum Purchase:
    100 units
    Inner Diameter:
    1/2"
    Overall Height:
    2-37/64"
    Overall Length:
    5"
    Bolt Hole to Bolt Hole:
    3-47/64"
    Base to Center:
    1-15/16"
    Housing Material:
    Thermoplastic
    Insert Material:
    Stainless Steel AISI-440C
    Lubrication:
    Chevron SRI-2 Grease
    Static Load:
    750 lbf
    Dynamic Load:
    1,280 lbf
    Country of Origin:
    China
    Interchange Numbers:
    SUCTP201-8, YAS-1/2-PT, MUCPPL202-10, UCVP202-10ES7, SUCP202-10-PBT, TP-SUCP202-10, SY-1/2TR, F-UCPR202-008/LP03, P2B-SCEZ-008-PCR, PB251CTWx1/2, P2B-SCEZ-008-PSS, F-UCPR202-10F1/LP09

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    SUCVP201-8 Pillow Block Unit

    Key Features

    SUCVP201-8 is a high quality Thermoplastic Pillow Block Housing with a Stainless Steel Ball Bearing. The bearingn has a wide inner ring with two set screws for attaching to the shaft and the housing comes with a grease feed for re-lubing the bearing. SUCVP201-8 equipped with two specifically designed set screws that are positioned in the inner ring of the ball bearing to lock and attach to the shaft. Our mounted block bearings are pre-lubricated with grease to allow it to be ready to use upon arrival.

    Applications / Industries

    SUCVP201-8 Mounted Blocks are used in a variety of applications such as Construction Equipment, Pumps, Manufacturing Equipment, Sporting and Consumer Goods, Conveyor and Fan Assemblies, Agricultural Machinery, HVAC System, Feed Mills, Underwater Applications, Chemical Processing, Food and Beverage Processing, Corrosive Environments and other Industrial Equipment.

    Product Videos

    Custom Field

    Inner Diameter 1/2"
    Overall Height 2-37/64"
    Overall Length 5"
    Bolt Hole to Bolt Hole 3-47/64"
    Base to Center 1-15/16"
    Housing Material Thermoplastic
    Insert Material Stainless Steel AISI-440C
    Lubrication Chevron SRI-2 Grease
    Static Load 750 lbf
    Dynamic Load 1,280 lbf
    Country of Origin China
    Interchange Numbers SUCTP201-8, YAS-1/2-PT, MUCPPL202-10, UCVP202-10ES7, SUCP202-10-PBT, TP-SUCP202-10, SY-1/2TR, F-UCPR202-008/LP03, P2B-SCEZ-008-PCR, PB251CTWx1/2, P2B-SCEZ-008-PSS, F-UCPR202-10F1/LP09
