  • Home
  • Ball Bearings
  • R Series
  • R4 Miniature Ball Bearing 1/4x5/8x0.196
  • R4 Miniature Ball Bearing 1/4x5/8x0.196 Front View
  • R4 Miniature Ball Bearing 1/4x5/8x0.196 Front View

    R4 Miniature Ball Bearing 1/4x5/8x0.196

    (You save )
    (No reviews yet) Write a Review
    SKU:
    R4
    Minimum Purchase:
    100 units
    Inner Diameter:
    1/4”
    Outer Diameter:
    5/8”
    Width:
    0.196”
    Material:
    Chrome Steel
    Lubrication:
    Light Oil
    Interchange Numbers:
    RI4, RI-4, R4C, R-4, S1K7, R8020X, DDRI-4, SSRI-4, R4 open
    Static Load:
    139 lbs
    Dynamic Load:
    333 lbs
    Grease RPM Limit:
    38,000 RPM
    Oil RPM Limit:
    45,000 RPM

    Adding to cart… category.add_cart_announcement
    Add to Wish List
    • Create New Wish List
    • Facebook
    • Email
    • Print
    • Twitter
    • Pinterest
    • Overview
    • Reviews

    Product Description

    Single Row Radial Precision Miniature Ball Bearing Both Sides Open and Pre-Lubricated with Oil

    Rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed and Shielded bearings are lubricated with oil or grease in the bearing factory, while open bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, electric motors, CNC machinery, trucks, mining equipment, train, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

    The R Series Radial Ball Bearings have a combination of an inner and outer ring with a cage containing a complement of precision balls. The R Series Single Row Radial Ball Bearings are used in the following: axial fans, clutch, drive axles, idler wheels, electric motors, roller skates, skateboards, snow mobiles, fishing reel, equipment, conveyor and many other industrial machines.

    Used in: DC Motors, Fan, Wheel, Fish Reel, Robotic systems, Align Helicopter, Trex700, Jewelry, Hand Piece, Hobby, RC Helicopters, RC Planes, RC Trucks, RC Cars, Beam Ball Bearing and much more

    Match #: RI4, RI-4, R4C, R-4, S1K7, R8020X, DDRI-4, SSRI-4, R4 open

    Product Videos

    Custom Field

    Inner Diameter 1/4”
    Outer Diameter 5/8”
    Width 0.196”
    Material Chrome Steel
    Lubrication Light Oil
    Interchange Numbers RI4, RI-4, R4C, R-4, S1K7, R8020X, DDRI-4, SSRI-4, R4 open
    Static Load 139 lbs
    Dynamic Load 333 lbs
    Grease RPM Limit 38,000 RPM
    Oil RPM Limit 45,000 RPM
