• LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Front Right Angled View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Front Left Angled View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Front View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Standing View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Standing Left View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Standing Right View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Bottom View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Bottom Right View
  • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm Bottom Left View

    • LMH10UU Oval Linear Motion Flange Ball Bushing 10x19x29mm LMT10UU

    Minimum Order: 100 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    LMT10UU
    Minimum Purchase:
    100 units
    Inner Diameter:
    10mm
    Outer Diameter:
    19mm
    Length:
    29mm
    Closure Type:
    Rubber Sealed
    Material:
    Chrome Steel SAE-52100
    Lubrication:
    Light Oil
    Static Load:
    247 lbf
    Dynamic Load:
    130 lbf
    Country of Origin:
    China
    Interchange Numbers:
    LFT10UU, SMT10UU, LHFC10, LMH10UU, CFTB10UU, LMT10-UU

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    LMT10UU Oval Linear Motion Flange Ball Bushing

    Key Features

    LMT10UU is an Oval Flanged Linear Ball Bushing manufactured to have both sides Rubber Sealed, pre-lubricated with Light Oil allowing for use upon delivery. Our Linear Motion Bushings are offered in both metric and inch sizes, open and adjustable types with rubber seals and flanged linear bearings.

    For the LMH-UU series, please note that LMH6 - LMH13 features a 2-bolt configuration on the housing (like shown in the images), while LMH16 - LMH30 feature a 4-bolt configuration on the housing. Please contact us for a spec sheet, should more details be needed.

    Applications / Industries

    LMT10UU Linear bearings can be used in a variety of different applications including Lab Equipment, Packaging Equipment, CNC Machinery, Robotic Equipment, Electronics, Appliances, Furniture, Automation Machinery, among others.

    Product Videos

    Custom Field

    Inner Diameter 10mm
    Outer Diameter 19mm
    Length 29mm
    Closure Type Rubber Sealed
    Material Chrome Steel SAE-52100
    Lubrication Light Oil
    Static Load 247 lbf
    Dynamic Load 130 lbf
    Country of Origin China
    Interchange Numbers LFT10UU, SMT10UU, LHFC10, LMH10UU, CFTB10UU, LMT10-UU
