• FR2-2RS Flanged Miniature Ball Bearing 1/8x3/8x5/32 Right Angled View
  • FR2-2RS Flanged Miniature Ball Bearing 1/8x3/8x5/32 Top View
  • FR2-2RS Flanged Miniature Ball Bearing 1/8x3/8x5/32 Left Angled View
  • FR2-2RS Flanged Miniature Ball Bearing 1/8x3/8x5/32 Front View
  • FR2-2RS Flanged Miniature Ball Bearing 1/8x3/8x5/32 Front View
  • FR2-2RS Flanged Miniature Ball Bearing 1/8x3/8x5/32 Bottom View

    • FR2-2RS Flanged Miniature Ball Bearing 1/8x3/8x5/32 Sealed

    Minimum Order: 100 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    FR2-2RS
    Minimum Purchase:
    100 units
    Inner Diameter:
    1/8"
    Outer Diameter:
    3/8"
    Width:
    5/32"
    Closure Type:
    Rubber Sealed
    Material:
    Chrome Steel SAE-52100
    Lubrication:
    Chevron SRI-2 Grease
    Static Load:
    49 lbf
    Dynamic Load:
    141 lbf
    Speed Limit:
    56,000 RPM
    Country of Origin:
    China
    Interchange Numbers:
    FR2RS, RIF-2DD, R2FCLLHH, FR2FF, RKS4012X, FR2PP, 33PP3, FR2.2RSJ1, 3759T29

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    FR2-2RS is a Precision Miniature Flanged Ball Bearing manufactured to have both sides Rubber Sealed and is pre-lubricated with Grease allowing it to be ready for use upon delivery. Made from Chrome Steel, FR2-2RS is a Miniature Ball Bearing that can withstand both moderate radial and axial loads while providing high performance. Our FR Series Miniature Flanged Ball Bearings have a Steel Flange located on the outer ring of the bearing to allow for easier locating on a housing while also preventing any axial movement of the bearing in the event of a thrust load being put onto it.

    Sizes: ID 0.125" x OD 0.375" x W 0.156" = ID 3.175mm x OD 9.525mm x W 3.962mm

    Interchange: FR2RS, RIF-2DD, R2FCLLHH, FR2FF, RKS4012X, FR2PP, 33PP3, FR2.2RSJ1, 3759T29

    Applications: Electric Fans, Automotives, RC Cars, RC Planes, RC Helicopters, Industrial & Medical Hand Pieces, Surgical Equipment, Household Electrical Appliances, Trex700, Medical Instruments, Surveillance Systems, Plastic Card Printers, Robotics, Pulmonary Assist Devices, Cryogenic Coolers, Flow Meters, Fuel Control, among others.

    Product Videos

    Custom Field

    Inner Diameter 1/8"
    Outer Diameter 3/8"
    Width 5/32"
    Closure Type Rubber Sealed
    Material Chrome Steel SAE-52100
    Lubrication Chevron SRI-2 Grease
    Static Load 49 lbf
    Dynamic Load 141 lbf
    Speed Limit 56,000 RPM
    Country of Origin China
    Interchange Numbers FR2RS, RIF-2DD, R2FCLLHH, FR2FF, RKS4012X, FR2PP, 33PP3, FR2.2RSJ1, 3759T29
