  • 6300-ZZ Ball Bearing 10x35x11
  • 6300-ZZ Ball Bearing 10x35x11 Front View
  • 6300-ZZ Ball Bearing 10x35x11 Front View

    6300-ZZ Ball Bearing 10x35x11

    (You save )
    (No reviews yet) Write a Review
    SKU:
    6300-ZZ
    Minimum Purchase:
    100 units
    Inner Diameter:
    10mm
    Outer Diameter:
    35mm
    Width:
    11mm
    Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Interchange Numbers:
    6300Z, 6300.2Z, 6300SS, 6300.2ZJ1, 300KSFF, 77300, 300KDD, 5U562, 6661K61
    Static Load:
    780 lbs
    Dynamic Load:
    1,840 lbs
    Grease RPM Limit:
    22,000 RPM
    Oil RPM Limit:
    26,000 RPM

    Adding to cart… category.add_cart_announcement
    Add to Wish List
    • Create New Wish List
    • Facebook
    • Email
    • Print
    • Twitter
    • Pinterest
    • Overview
    • Reviews

    Product Description

    The 6300-ZZ is a 10mm single row radial ball bearing that’s shielded with metal on both sides and pre-lubricated with bearing grease. It’s a 35mm OD shielded ball bearing 6300Z made of chrome steel and features deep groove geometry that’s perfect for high speeds and heavy radial and axial loads. Rolling bearings like 77300 use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed and Shielded bearings are lubricated with oil or grease in the bearing factory, while open bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan.

    6300-ZZ is used in a range of applications from agricultural machinery to conveying equipment, electric motors, CNC machinery, trucks, mining equipment, train, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, motorcycles, household appliances, power tools and machines, gear boxes, and among others.

    Usage: Electric Motor, Fan, Power Tools, Conveyor Bearing, Pilot Bearing, Casters Bearing, Dolly Wheel Bearing, Alternator, Gear Box, Tension Pulley, Wheel Bearing and much more.

    Match #: 6300Z, 6300.2Z, 6300SS, 6300.2ZJ1, 300KSFF, 77300, 300KDD, 5U562, 6661K61

    Product Videos

    Custom Field

    Inner Diameter 10mm
    Outer Diameter 35mm
    Width 11mm
    Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Interchange Numbers 6300Z, 6300.2Z, 6300SS, 6300.2ZJ1, 300KSFF, 77300, 300KDD, 5U562, 6661K61
    Static Load 780 lbs
    Dynamic Load 1,840 lbs
    Grease RPM Limit 22,000 RPM
    Oil RPM Limit 26,000 RPM
