• UFL004-2RS Mini Zinc Flange Eccentric Bearing Unit 20mm bore Side View
  • UFL004-2RS Mini Zinc Flange Eccentric Bearing Unit 20mm bore Side View

    • 20mm bore UFL004-2RS Mini Zinc Flange Eccentric with Locking Collar Bearing UFL004

    Minimum Order: 100 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    UFL004
    Minimum Purchase:
    100 units
    Inner Diameter:
    20mm
    Overall Length:
    90mm
    Overall Height:
    55mm
    Bolt Hole to Bolt Hole:
    71mm
    Housing Material:
    Zinc Alloy
    Insert Material:
    Chrome Steel SAE-52100
    Lubrication:
    Chevron SRI-2 Grease
    Static Load:
    1,135 lbf
    Dynamic Load:
    2,113 lbf
    Speed Limit:
    21,000 RPM
    Country of Origin:
    China
    Interchange Numbers:
    UFL04UU, UFL04U, UFL4RS, UVFL4LL, UFL004

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    UFL004-2RS bearing is a Miniature Zinc Oval Flange Housing with Eccentric Locking Collar Insert Ball Bearing. This unit features a machined collar with a single set screw which attaches to the inner ring of the insert ball bearing. This single set screw secures the position of the eccentric locking collar onto a shaft. This locking method is recommended for most applications since it does less damage to the shaft than a normal set screw locking system. UFL004-2RS comes pre-Lubricated with Grease, ready for use upon delivery.

    Sizes: 20mm Bore x 90mm Overall Length x 55mm Overall Height

    Applications: Zinc Flange Bearings are widely used in various Consumer Goods, HVAC Systems, Manufacturing Equipment, Agriculture, Automotive, Conveyor Systems, Film Processing Machinery, Fitness Equipment, Fan Assemblies, Pump, Sporting, among others.

    Product Videos

    Custom Field

    Inner Diameter 20mm
    Overall Length 90mm
    Overall Height 55mm
    Bolt Hole to Bolt Hole 71mm
    Housing Material Zinc Alloy
    Insert Material Chrome Steel SAE-52100
    Lubrication Chevron SRI-2 Grease
    Static Load 1,135 lbf
    Dynamic Load 2,113 lbf
    Speed Limit 21,000 RPM
    Country of Origin China
    Interchange Numbers UFL04UU, UFL04U, UFL4RS, UVFL4LL, UFL004
