• UCFC214 Round Flange Housing 4 Bolt Set Screw Ball Bearing 70mm Bore Top View
  • UCFC214 Round Flange Housing 4 Bolt Set Screw Ball Bearing 70mm Bore Side View
  • UCFC214 Round Flange Housing 4 Bolt Set Screw Ball Bearing 70mm Bore Bottom View

    • UCFC214 Four Bolt Circle Flange Mounted Bearing 70mm Bore

    Minimum Order: 100 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    UCFC214
    Minimum Purchase:
    100 units
    Bore Size:
    70mm
    Bolt Hole to Bolt Hole:
    4-59/64" (125mm)
    Static Load:
    9,900 lbs
    Dynamic Load:
    13,900 lbs
    Housing Material:
    Cast Iron
    Bearing Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Interchange Numbers:
    VFC-214, UCFC214
    Speed Limit:
    2,450 RPM

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    UCFC214 Round Flange 4 Bolt Flange Light Duty Housing with Set Screw Bearing in Unit, Pre-Lubricated with Grease and Grease Feeding Access

    UCFC214 flange mounted bearing has a cast iron flange housing, four bolt holes, and a 70mm inside diameter. This ready-to-mount unit has a cast iron housing, chrome steel bearings, and is designed for efficient operation at a wide range of speeds. The unit is secured to the shaft with set screws to prevent slippage. These bearings are most commonly used in mechanical equipment where moderate loads and shaft speeds are involved where the shaft and mounting surface are perpendicular to each other.

    Match#: VFC-214, UCFC214

    Product Videos

    Custom Field

    Bore Size 70mm
    Bolt Hole to Bolt Hole 4-59/64" (125mm)
    Static Load 9,900 lbs
    Dynamic Load 13,900 lbs
    Housing Material Cast Iron
    Bearing Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Interchange Numbers VFC-214, UCFC214
    Speed Limit 2,450 RPM
