Pillow Block Bearings
SUCP211-32 Stainless Steel Ball Bearing in Cast Iron Housing 2" Bore
- Free shipping on most orders
- Ships from Glendale, CA
Specifications
Dimensions
| Bore (inner diameter) | 2" |
|---|---|
| Overall Length | 8-1/8" |
| Overall Height | 4-7/16" |
| Base to center height | 2-1/2" |
| Bolt-hole spacing | 6-23/32" |
Construction
| Bearing Material | Stainless Steel AISI-440C |
|---|---|
| Housing Material | Cast Iron |
| Lubrication | Chevron SRI-2 Grease |
| Country of Origin | China |
Performance
| Static Load | 6,607 lbs |
|---|---|
| Dynamic Load | 9,743 lbs |
| Speed Limit | 3,100 RPM |
Interchange numbers 4
- SSUCP211-32
- MUCP211-32
- SUCP211-32
- SPS-32
Ordering & returns
Lead time
Lead times depend on the part and quantity. We confirm availability and timing when we respond to your quote request.
Before you order
Please verify dimensions and specifications before ordering. Custom and production orders have specific cancellation and return restrictions.
Shipping and returns
Shipping options and charges are confirmed with your order. Read our full Shipping & Returns policy.
Description
SUCP211-32 Stainless Steel Ball Bearing
Key Features
SUCP211-32 is a Cast Iron Pillow Block Housing combined with a Stainless Steel Set Screw Insert Ball Bearing. This unit is a standard duty pillow block bearing with a wide inner ring, a standard base to center height and a 45˚ degree grease fitting allowing for re-lubrication of the insert bearing. SUCP211-32 Pillow Block Bearing is equipped with two set screws, that are positioned on the extended inner ring of the insert ball bearing, to lock and attach to the shaft. Our Mounted Block Bearing Units have been pre-lubricated with Grease, allowing them to be ready for use upon arrival.
Applications / Industries
SUCP211-32 Mounted Blocks are used in a variety of applications such as Agriculture, Automotive, Construction, Pump, Manufacturing Equipment, Sporting and Consumer Goods, Conveyor and Fan Assemblies, Farm Machinery, HVAC, Feed Mill, Economical housed bearing solution among other Industrial Equipment.
