• LM11949-LM11910 - Set A2 bearing
  • LM11949/10 roller bearing 4T-LM11949/10

    • LM11949-LM11910 - Set A2 Tapered Roller Bearing 3/4x1-25/32x39/64" ITJ

    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Wholesale Pricing By Quote — Request a Quote
    Write a Review
    SKU:
    LM11949/10-ITJ
    UPC:
    1200106138983
    Inner Diameter:
    3/4"
    Outer Diameter:
    1-25/32"
    Width:
    39/64"
    Material:
    Chrome Steel SAE-52100
    Lubrication:
    Chevron SRI-2 Grease
    Static Load:
    6,767 lbs
    Dynamic Load:
    8,273 lbs
    Speed Limit:
    9,400 RPM
    Country of Origin:
    Japan
    Interchange Numbers:
    A2, S2, Set2, LM11949, LM11910, 4T-LM11949, 4T-LM11910, 05404500, 05404400
    Request a Quote for 0+ Units

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    LM11949/10 Tapered Roller Bearing

    Key Features

    LM11949/10 Tapered Roller Bearings consist of a two piece cup and cone assembly. The outer ring makes up the cup and the inner ring, rollers, and cage assembly make the cone. These parts of the bearing are detachable, the cone assembly is narrower in one end and the races are built with one side narrower as well to match the rollers. This design makes this bearing capable of supporting heavy loads in both axial and radial directions. Our LM11949/10 Tapered Roller Bearings are ideal for environments where high speed and heavy loads occur, and low friction is needed.

    Applications / Industries

    LM11949/10 Tapered Roller Bearings are designed for many applications such as Gearboxes, Hoisting Equipment, Rolling Mills, Mining Industry Machines, Steer axle, Drive axles, Pusher axles, Tag axles, Engines, and Propellers.

    Product Videos

    Custom Field

    Inner Diameter 3/4"
    Outer Diameter 1-25/32"
    Width 39/64"
    Material Chrome Steel SAE-52100
    Lubrication Chevron SRI-2 Grease
    Static Load 6,767 lbs
    Dynamic Load 8,273 lbs
    Speed Limit 9,400 RPM
    Country of Origin Japan
    Interchange Numbers A2, S2, Set2, LM11949, LM11910, 4T-LM11949, 4T-LM11910, 05404500, 05404400
