Tapered Roller Bearings
LM11949-LM11910 - Set A2 Tapered Roller Bearing 3/4x1-25/32x39/64" ITJ
- Free shipping on most orders
- Ships from Glendale, CA
Specifications
Dimensions
| Bore (inner diameter) | 3/4" |
|---|---|
| Outer Diameter | 1-25/32" |
| Width | 39/64" |
Construction
| Material | Chrome Steel SAE-52100 |
|---|---|
| Lubrication | Chevron SRI-2 Grease |
| Country of Origin | Japan |
Performance
| Static Load | 6,767 lbs |
|---|---|
| Dynamic Load | 8,273 lbs |
| Speed Limit | 9,400 RPM |
Interchange numbers 9
- A2
- S2
- Set2
- LM11949
- LM11910
- 4T-LM11949
- 4T-LM11910
- 05404500
- 05404400
Ordering & returns
Lead time
Lead times depend on the part and quantity. We confirm availability and timing when we respond to your quote request.
Before you order
Please verify dimensions and specifications before ordering. Custom and production orders have specific cancellation and return restrictions.
Shipping and returns
Shipping options and charges are confirmed with your order. Read our full Shipping & Returns policy.
Description
LM11949/10 Tapered Roller Bearing
Key Features
LM11949/10 Tapered Roller Bearings consist of a two piece cup and cone assembly. The outer ring makes up the cup and the inner ring, rollers, and cage assembly make the cone. These parts of the bearing are detachable, the cone assembly is narrower in one end and the races are built with one side narrower as well to match the rollers. This design makes this bearing capable of supporting heavy loads in both axial and radial directions. Our LM11949/10 Tapered Roller Bearings are ideal for environments where high speed and heavy loads occur, and low friction is needed.
Applications / Industries
LM11949/10 Tapered Roller Bearings are designed for many applications such as Gearboxes, Hoisting Equipment, Rolling Mills, Mining Industry Machines, Steer axle, Drive axles, Pusher axles, Tag axles, Engines, and Propellers.
