• FB224M50H 4-Bolt Flange Bearing Replacement 50mm Bore Right Angled View
  • FB224M50H 4-Bolt Flange Bearing Replacement 50mm Bore Left Angled View
  • FB224M50H 4-Bolt Flange Bearing Replacement 50mm Bore Specification Sheet

    • FB224M50H 4-Bolt Flange Bearing Replacement 50mm Bore CS4F10-050

    Minimum Order: 1 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    CS4F10-050
    Minimum Purchase:
    1 unit
    Inner Diameter:
    50mm
    Bolt Hole to Bolt Hole:
    4-1/16" (103.2mm)
    Overall Length:
    5-5/16" (135mm)
    Static Load:
    25,313 lbs
    Dynamic Load:
    22,095 lbs
    Housing Material:
    Cast Iron
    Bearing Material:
    Chrome Steel SAE-52100
    Lubrication:
    Lithium Complex Grease
    Speed Limit:
    5,400 RPM
    Interchange Numbers:
    FB224M50H, QAFL10A-050S, 19211050, SR2-FB4-50MMNE, XS4F410, CS4F10-050

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    CS4F10-050 is a Set Screw Locking 4-Bolt Cast Iron Square Flange Spherical Roller Pillow Block Bearing that has been pre-lubricated with lithium complex grease and features an innovative new design to accomodate thermal expansion.

    Experience superior performance with the CS4F10-050 bearing, a cutting-edge solution designed for maximum grip force without compromising shaft integrity. This bearing features a set screw locking collar with a 90 degree nylon patch, providing maximum holding power. Its triple lip seal, paired with a stainless steel flinger, adapts to shaft misalignment while providing unrivaled protection against contamination. Engineered for versatility, this bearing effortlessly transitions between non-expansion and expansion configurations, offering enhanced adaptability. With a built-in grease feed, the CS4F10-050 allows for convenient relubrication, outperforming older models and serving as an ideal replacement for select Dodge and Timken bearings. Upgrade your application with this advanced solution for unmatched reliability and efficiency.

    Interchange: FB224M50H, QAFL10A-050S, 19211050, SR2-FB4-50MMNE, XS4F410, CS4F10-050

    Product Videos

    Custom Field

    Inner Diameter 50mm
    Bolt Hole to Bolt Hole 4-1/16" (103.2mm)
    Overall Length 5-5/16" (135mm)
    Static Load 25,313 lbs
    Dynamic Load 22,095 lbs
    Housing Material Cast Iron
    Bearing Material Chrome Steel SAE-52100
    Lubrication Lithium Complex Grease
    Speed Limit 5,400 RPM
    Interchange Numbers FB224M50H, QAFL10A-050S, 19211050, SR2-FB4-50MMNE, XS4F410, CS4F10-050
