  • 682-ZZ Miniature Ball Bearing 2x5x2.3 Front View

    • 682-ZZ Miniature Ball Bearing 2x5x2.3

    Write a Review
    SKU:
    682-ZZ
    Minimum Purchase:
    100 units
    Inner Diameter:
    2mm
    Outer Diameter:
    5mm
    Width:
    2.3mm
    Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Interchange Numbers:
    L-520ZZ , L520ZZ , MR682ZZ , MR682-ZZ , R-520ZZ
    Static Load:
    11 lbs
    Dynamic Load:
    37 lbs
    Grease RPM Limit:
    85,000 RPM
    Oil RPM Limit:
    100,000 RPM

    Product Description

    682-ZZ Bearing is Precision ABEC1 Miniature Radial Ball Bearing

    Used in : Jewelry, Hand Piece, Hobby, RC Helicopters, RC Planes, RC Trucks, RC Cars, Beam Ball Bearing and much more

    Rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed and Shielded bearings are lubricated with oil or grease in the bearing factory, while open bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, electric motors, CNC machinery, trucks, mining equipment, train, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

    Match #: L-520ZZ , L520ZZ , MR682ZZ , MR682-ZZ , R-520ZZ

    Product Videos

    Custom Field

    Inner Diameter 2mm
    Outer Diameter 5mm
    Width 2.3mm
    Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Interchange Numbers L-520ZZ , L520ZZ , MR682ZZ , MR682-ZZ , R-520ZZ
    Static Load 11 lbs
    Dynamic Load 37 lbs
    Grease RPM Limit 85,000 RPM
    Oil RPM Limit 100,000 RPM
