    6706-2RS Ball Bearing 30x37x4

    (You save )
    (No reviews yet) Write a Review
    SKU:
    6706-2RS
    Minimum Purchase:
    100 units
    Inner Diameter:
    30mm
    Outer Diameter:
    37mm
    Width:
    4mm
    Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Interchange Numbers:
    6706RS, 6706LLU, 6706LLB, 6706DDU, 6706VV, 6706.2RSJ1, 6706EE, 6706 2RU
    Static Load:
    209 lbs
    Dynamic Load:
    253 lbs
    Grease RPM Limit:
    17,000 RPM
    Oil RPM Limit:
    20,000 RPM

    Adding to cart… category.add_cart_announcement
    Add to Wish List
    • Create New Wish List
    • Facebook
    • Email
    • Print
    • Twitter
    • Pinterest
    • Overview
    • Reviews

    Product Description

    6706-2RS is used in a range of applications from water-jet machinery to 3D printing equipment, electric motors, CNC machinery, trucks, medical equipment, RC Hobby, robotics systems, dental equipment, camera-mount, rolling mills, ship rudder shafts, and aggregate crushers, motorcycles, household appliances, power tools and machines, gear boxes, and among others.

    Rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed and Shielded bearings are lubricated with oil or grease in the bearing factory, while open bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, electric motors, CNC machinery, trucks, mining equipment, train, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

    Common Uses: Electric Motor, Camera-Mount, Pulley, Alternator, Generator, Fans, Medical Equipment, Wheels, 3D Printing, Conveyors Roller, Printers, CNC Machinery, RC Hobby, Robotics and much more

    Match #: 6706RS, 6706LLU, 6706LLB, 6706DDU, 6706VV, 6706.2RSJ1, 6706EE, 6706 2RU

    Product Videos

    Custom Field

    Inner Diameter 30mm
    Outer Diameter 37mm
    Width 4mm
    Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Interchange Numbers 6706RS, 6706LLU, 6706LLB, 6706DDU, 6706VV, 6706.2RSJ1, 6706EE, 6706 2RU
    Static Load 209 lbs
    Dynamic Load 253 lbs
    Grease RPM Limit 17,000 RPM
    Oil RPM Limit 20,000 RPM
