  • 6703-ZZ Ball Bearing 17x23x4
  • 6703-ZZ Ball Bearing 17x23x4 Front View
  • 6703-ZZ Ball Bearing 17x23x4 Front View

    6703-ZZ Ball Bearing 17x23x4

    (You save )
    (No reviews yet) Write a Review
    SKU:
    6703-ZZ
    Minimum Purchase:
    100 units
    Inner Diameter:
    17mm
    Outer Diameter:
    23mm
    Width:
    4mm
    Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Interchange Numbers:
    6703Z, 6703.2ZR, 6703ZZ, 61703.2ZJ1, MR6703ZZ
    Static Load:
    147 lbs
    Dynamic Load:
    224 lbs
    Grease RPM Limit:
    26,000 RPM
    Oil RPM Limit:
    31,000 RPM

    Adding to cart… category.add_cart_announcement
    Add to Wish List
    • Create New Wish List
    • Facebook
    • Email
    • Print
    • Twitter
    • Pinterest
    • Overview
    • Reviews

    Product Description

    6703-ZZ Precision Single Row Radial Ball Bearing Both Sides Metal Shielded and Pre-Lubricated with Grease

    Rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed and Shielded bearings are lubricated with oil or grease in the bearing factory, while open bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, electric motors, CNC machinery, trucks, mining equipment, train, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

    Common Uses: Electric Motor, Camera-Mount, Pulley, Alternator, Generator, Fans, Medical Equipment, Wheels, 3D Printing, Conveyors Roller, Printers, CNC Machinery, RC Hobby, Robotics and much more

    Match #: 6703Z, 6703.2ZR, 6703ZZ, 61703.2ZJ1, MR6703ZZ

    Product Videos

    Custom Field

    Inner Diameter 17mm
    Outer Diameter 23mm
    Width 4mm
    Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Interchange Numbers 6703Z, 6703.2ZR, 6703ZZ, 61703.2ZJ1, MR6703ZZ
    Static Load 147 lbs
    Dynamic Load 224 lbs
    Grease RPM Limit 26,000 RPM
    Oil RPM Limit 31,000 RPM
