  • 605-2RS Miniature Ball Bearing 5x14x5
  • 605-2RS Miniature Ball Bearing 5x14x5 Front View
  • 605-2RS Miniature Ball Bearing 5x14x5 Front View

    605-2RS Miniature Ball Bearing 5x14x5

    (You save )
    (No reviews yet) Write a Review
    SKU:
    605-2RS
    Minimum Purchase:
    100 units
    Inner Diameter:
    5mm
    Outer Diameter:
    14mm
    Width:
    5mm
    Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Interchange Numbers:
    R1450-2RS, 605RS, 605DDU, 605VV, 605LLU, 605LLB, 605-2RSR, 605-2RS1, R1450PP
    Static Load:
    115 lbs
    Dynamic Load:
    300 lbs
    Grease RPM Limit:
    40,000 RPM
    Oil RPM Limit:
    50,000 RPM

    Adding to cart… category.add_cart_announcement
    Add to Wish List
    • Create New Wish List
    • Facebook
    • Email
    • Print
    • Twitter
    • Pinterest
    • Overview
    • Reviews

    Product Description

    605-2RS Bearing is Precision ABEC1 Miniature Radial Ball Bearing

    Used in: Jewelry, Hand Piece, Hobby, RC Helicopters, RC Planes, RC Trucks, RC Cars, Beam Ball Bearing

    Rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed and Shielded bearings are lubricated with oil or grease in the bearing factory, while open bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, electric motors, CNC machinery, trucks, mining equipment, train, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

    Match #: R1450-2RS, 605RS, 605DDU, 605VV, 605LLU, 605LLB, 605-2RSR, 605-2RS1, R1450PP

    Product Videos

    Custom Field

    Inner Diameter 5mm
    Outer Diameter 14mm
    Width 5mm
    Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Interchange Numbers R1450-2RS, 605RS, 605DDU, 605VV, 605LLU, 605LLB, 605-2RSR, 605-2RS1, R1450PP
    Static Load 115 lbs
    Dynamic Load 300 lbs
    Grease RPM Limit 40,000 RPM
    Oil RPM Limit 50,000 RPM
