    5204-ZZ Ball Bearing 20x47x20.6

    (You save )
    (No reviews yet) Write a Review
    SKU:
    5204-ZZ
    Minimum Purchase:
    100 units
    Inner Diameter:
    20mm
    Outer Diameter:
    47mm
    Width:
    20.6mm
    Material:
    Chrome Steel
    Lubrication:
    Chevron SRI-2 Grease
    Interchange Numbers:
    FS55504, 77504, 3204.2ZTN9, 5204CFF, B5204.2ZTN9, B5204-2ZRTN, 3204ZZ, 5204Z, 5204ZZ
    Static Load:
    2,710 lbs
    Dynamic Load:
    4,300 lbs
    Grease RPM Limit:
    8,800 RPM
    Oil RPM Limit:
    12,000 RPM

    Adding to cart… category.add_cart_announcement
    Add to Wish List
    • Create New Wish List
    • Facebook
    • Email
    • Print
    • Twitter
    • Pinterest
    • Overview
    • Reviews

    Product Description

    5204-2Z has a 20-degree contact angle, pressed steel cage, and normal clearance rating. 5204-ZZ supports radial loads, thrust loads in both directions, and combined loads, and occupies less thrust space than a pair of single-row angular contact ball bearings mounted together. Because the two rows of rolling elements are mounted back-to-back, the 5204.Z bearing arrangement is relatively rigid and can accommodate tilting moments. The 5200 series has a smaller cross section than the 5300 series, making it suitable for smaller spaces, lighter loads, and higher speeds. This 5204-KDD bearing is made of low-alloy, through-hardened carbon chromium steel for durability and resistance to deformity under heavy loads. The 20-degree contact angle of the balls in relation to the raceways gives the bearing a greater capacity for supporting thrust loads over bearings with a standard contact angle of 0 degrees. This bearing 5204-FF has a pressed steel cage to prevent the balls from coming into contact with each other during use, reducing friction, vibration, and noise. The 5204.2Z bearing has a normal axial internal clearance designation, making it suitable for applications where the load and speeds do not result in thermal expansion. This 5204.Z clearance provides latitude for self-realignment and compensates for static and dynamic alignment errors. This angular contact ball bearing is for use in commercial and industrial applications including pumps and compressors, automotive drives, gearboxes, and printing machines, among others.

    Match #: FS55504, 77504, 3204.2ZTN9, 5204CFF, B5204.2ZTN9, B5204-2ZRTN, 3204ZZ, 5204Z, 5204ZZ

    Product Videos

    Custom Field

    Inner Diameter 20mm
    Outer Diameter 47mm
    Width 20.6mm
    Material Chrome Steel
    Lubrication Chevron SRI-2 Grease
    Interchange Numbers FS55504, 77504, 3204.2ZTN9, 5204CFF, B5204.2ZTN9, B5204-2ZRTN, 3204ZZ, 5204Z, 5204ZZ
    Static Load 2,710 lbs
    Dynamic Load 4,300 lbs
    Grease RPM Limit 8,800 RPM
    Oil RPM Limit 12,000 RPM
