• 51113 Thrust Ball Bearing 65x90x18mm Front View
  • 51113 Thrust Ball Bearing 65x90x18mm Flat Set View
  • 51113 Thrust Ball Bearing 65x90x18mm Flat Set View
  • 51113 Thrust Ball Bearing 65x90x18mm Disassembled Outer Race View
  • 51113 Thrust Ball Bearing 65x90x18mm Disassembled Inner Race View

    • 51113 Thrust Ball Bearing 65x90x18 Grooved 51113X

    Minimum Order: 100 UnitsThis item is sold in bulk quantities only
    Wholesale Pricing — By Quote

    Pricing depends on quantity and current production runs. Add this item to a quote and we'll reply with unit pricing and lead time, in writing.

    Write a Review
    SKU:
    51113
    Minimum Purchase:
    100 units
    Inner Diameter:
    65mm
    Outer Diameter:
    90mm
    Width:
    18mm
    Material:
    Chrome Steel SAE-52100
    Lubrication:
    Light Oil
    Static Load:
    26,300 lbf
    Dynamic Load:
    9,350 lbf
    Speed Limit:
    2,400 RPM
    Country of Origin:
    China
    Interchange Numbers:
    51113A, 51113X, 8113, ELP65, 65TA11, 51113

    Before you order: most items are produced to order — lead times are confirmed with your quote. Once placed, most orders cannot be cancelled or returned, so please verify dimensions and specifications first. Free shipping applies to most orders. Read the full Shipping & Returns policy.

    Product Description

    51113 Grooved Thrust Ball Bearing

    Key Features

    51113 Thrust Ball Bearings come in a set of one Caged Ball Bearing and Two Grooved Washers and are composed of ball rolling elements. Their appearance sets them apart from the other types of bearings since the outer race and inner race, called shaft and housing washers, are layered with the cage in between. This assembly makes them look like three stacked washers. Thrust ball bearings can sustain loads at high speeds and their uses are ideal for axial loads only. Our inventory of thrust ball bearings includes single row thrust ball bearings and varies in sizes. Our Thrust Ball Bearings are equipped with washers either with or without a groove and are made of chrome steel.

    Applications / Industries

    51113 is used in a variety of industries such as Agricultural Machinery, Conveying Equipment, Robotics, Dental Equipment, Elevators, Rolling Mills, Ship Rudder Shafts, and Aggregate Crushers.

    Product Videos

    Custom Field

    Inner Diameter 65mm
    Outer Diameter 90mm
    Width 18mm
    Material Chrome Steel SAE-52100
    Lubrication Light Oil
    Static Load 26,300 lbf
    Dynamic Load 9,350 lbf
    Speed Limit 2,400 RPM
    Country of Origin China
    Interchange Numbers 51113A, 51113X, 8113, ELP65, 65TA11, 51113
