| Bore (inner diameter) | 17mm |
|---|---|
| Outer Diameter | 47mm |
| Width | 15.25mm |
| Material | Chrome Steel SAE-52100 |
|---|---|
| Lubrication | Light Oil |
| Country of Origin | China |
| Static Load | 5,620 lbs |
|---|---|
| Dynamic Load | 6,320 lbs |
| Speed Limit | 11,000 RPM |
Lead times depend on the part and quantity. We confirm availability and timing when we respond to your quote request.
Please verify dimensions and specifications before ordering. Custom and production orders have specific cancellation and return restrictions.
Shipping options and charges are confirmed with your order. Read our full Shipping & Returns policy.
30303 is a Precision Tapered Roller Bearing in a Set of Cone and Cup. This is the most basic and most widely used type of Tapered Roller Bearing. It consists of two main separable parts: the cone assembly (inner ring) and the cup (outer ring). It is typically mounted in opposing pairs on a Shaft Wheel Bearing Assembly. Our 30300-Series Tapered Roller Bearings provide enhanced performance in demanding applications and are pre-lubricated with light oil to ensure they are ready to use upon arrival.
30303 Tapered Roller Bearings are used in a range of applications from Agricultural Machinery to Conveyor Systems, Electric Motors, Trucks, Robotics, Dental Equipment, Gear Drives, Rolling Mills, Ship Rudder Shafts, Aggregate Crushers, among others.
