    • POS4EC 4mm Maintenance-Free Type Pilloball Male Rod End Bearing Right Hand Thread

    Write a Review
    SKU:
    POS4EC
    Minimum Purchase:
    50 units
    Bore Size:
    4mm
    Base to Center:
    1-3/16" (30mm)
    Thread:
    M4x0.7
    Overall Height:
    1-29/64" (37mm)
    Outer Diameter:
    35/64" (14mm)
    Static Load:
    463 lbs
    Dynamic Load:
    1,113 lbs
    Thread Direction:
    Right Hand

    Product Description

    This type has superior anti-corrosion properties as the body is zinc chromate treated and the spherical inner ring is chromium plated on the sphere surface after heat treatment and grinding.

    A special PTFE liner, reinforced with copper alloy meshes, which is superior in anti-wear properties with little creep deformation is used for lining on the sliding surface of the body, and this type is maintenance- free.

    POS4EC, which has a male thread on the body, is available.

    Product Videos

    Custom Field

    Bore Size 4mm
    Base to Center 1-3/16" (30mm)
    Thread M4x0.7
    Overall Height 1-29/64" (37mm)
    Outer Diameter 35/64" (14mm)
    Static Load 463 lbs
    Dynamic Load 1,113 lbs
    Thread Direction Right Hand
