    • PHS22ECL 22mm Maintenance-Free Type Pilloball Female Rod End Bearing Left Hand Thread

    Write a Review
    SKU:
    PHS22ECL
    Minimum Purchase:
    50 units
    Bore Size:
    22mm
    Base to Center:
    3-5/16" (84mm)
    Thread:
    M22x1.5
    Overall Height:
    4-19/64" (109mm)
    Outer Diameter:
    1-31/32" (50mm)
    Static Load:
    8,183 lbs
    Dynamic Load:
    16,793 lbs
    Thread Direction:
    Left Hand

    Product Description

    This type has superior anti-corrosion properties as the body is zinc chromate treated and the spherical inner ring is chromium plated on the sphere surface after heat treatment and grinding.

    A special PTFE liner, reinforced with copper alloy meshes, which is superior in anti-wear properties with little creep deformation is used for lining on the sliding surface of the body, and this type is maintenance-free.

    PHS22ECL, which has a female thread in the body, is available.

    Product Videos

    Custom Field

    Bore Size 22mm
    Base to Center 3-5/16" (84mm)
    Thread M22x1.5
    Overall Height 4-19/64" (109mm)
    Outer Diameter 1-31/32" (50mm)
    Static Load 8,183 lbs
    Dynamic Load 16,793 lbs
    Thread Direction Left Hand
